Low Noise 1550nm Nanosecond Pulse Fiber Laser Module For DTS Sensor System can be used in fiber laser, fiber sensor system and other applications.
The nanosecond pulse laser adopts a unique circuit and optical optimization design. The output pulse width, peak power and repetition frequency can be adjusted. The working wavelength and power output are stable, and the noise is low. The RS232 serial port is remote controlled. It can be used in fiber laser, fiber sensor system and other applications.
All fiber structure;
Pulse width, repetition frequency and power adjustable;
Benchtop or module package.
High power laser seed source;
Optical fiber sensor.
|Output peak power||W||5～30 Adjustable||Customizable|
|Pulse width||ns||1～30 Adjustable|
|Repetitive frequency||KHz||10～1000 Adjustable|
|Trigger mode||-||Internal trigger||SMA Interface|
|Fiber type||-||SM fiber, FC/APC|
|Power supply||V||AC 110~240V||Benchtop|
|Operating temperature||℃||-5 ~ +60|
|Storage temperature||℃||-20 ~ +75|
All products have been tested before shipping out;
All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)
We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);
If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;
If the items are defective, please notify us within 3 days of delivery;
Any items must be returned in their original condition to qualify for a refund or replacement;
The buyer is responsible for all the shipping cost incurred.
A: We have 10W, 30W, 50W options,We can also customize according to your requirement.Q: About the package dimension, do you have any requirement?
A: We have the module type and benchtop for choice.
