780nm Femtosecond Pulse Fiber Laser For Multiphoton Imaging use the latest femtosecond laser technology to achieve stable output of 780nm femtosecond pulse laser. With the characteristics of narrow laser pulse and high peak power.
780nm Femtosecond Pulse Fiber Laser use the latest femtosecond laser technology to achieve stable output of 780nm femtosecond pulse laser. With the characteristics of narrow laser pulse and high peak power.
780nm Femtosecond Pulse Fiber Laser use the latest femtosecond laser technology to achieve stable output of 780nm femtosecond pulse laser. With the characteristics of narrow laser pulse and high peak power.
Pulse < 100fs, 780nm wavelength;
Automatic maintenance free;
High stability polarization maintaining fiber.
Multiphoton excitation imaging;
Two photon absorption;
Ultrafast laser phenomenon.
| Parameters | Unit | Values | Notes |
| Operating Wavelength | nm | 780±10 | |
| Spectral width | nm | 20 | |
| Pulse width | fs | <100 | Customized |
| Output power | mW | >30 | Customized |
| Power instability | - | < 1% | |
| Repetitive frequency | MHz | 80 | Customized |
| Repetition rate instability | Hz | <100 | |
| Monopulse energy | nJ | >1 | |
| Laser polarization | - | Linear polarization | |
| Output mode | - | Space light | |
| Preheating time | min | < 1 | |
| Operating temperature | ℃ | 5 ~ 45 | |
| Operating humidity | % | 0 ~ 70 | |
| Control mode | - | Push-button | |
|
Synchronous electrical signal interface |
- | SMA | |
| Dimensions | mm | 260(W)×280(D)×120(H) | Benchtop |
| 200(W)×121(D)×55(H) | Module | ||
| Power supply | V | AC 110~240V | Benchtop |
| DC 5V/4A | Module |
All products have been tested before shipping out;
All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)
We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);
If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;
If the items are defective, please notify us within 3 days of delivery;
Any items must be returned in their original condition to qualify for a refund or replacement;
The buyer is responsible for all the shipping cost incurred.
A: we have 50fs, 100fs, 200fs, 500fs options, we can also customize according to your requirements.
Q: What is the requirement for the output power?A: We have 1mW, 10mW, 50mW, 100mW options, we can also customize according to your requirements.
Q: About the package dimension, do you have any requirement?A: We have two kind of options, module type and benchtop type.
