850nm 10mW Superluminescent Diode sld diode

The 850nm 10mW Superluminescent Diode sld diode is a light source for ophthalmic and medical OCT application, fiber transmission systems, fiber optic gyros, fiber optic sensors,optical coherence tomography, optical measurements. The diode is packaged in 14-pin standard butterfly package with monitor photodiode and thermo-electric cooler (TEC). Module is pigtailed with single mode polarization maintaining fiber and connectorized by FC/APC connector.

Send Inquiry

Product Description

1. Introduction of 850nm 10mW Superluminescent Diode sld diode

The 850nm 10mW Superluminescent Diode sld diode is a light source for ophthalmic and medical OCT application, fiber transmission systems, fiber optic gyros, fiber optic sensors,optical coherence tomography, optical measurements. The diode is packaged in 14-pin standard butterfly package with monitor photodiode and thermo-electric cooler (TEC). Module is pigtailed with single mode polarization maintaining fiber and connectorized by FC/APC connector.

2. Features of 850nm 10mW Superluminescent Diode sld diode

High output power 10mW;

14PIN BTF Package;

3dB bandwidth of >35nm;

Operating Temperature -45~+70℃;

SM fiber or PM fiber pigtail.

3. Application of 850nm 10mW Superluminescent Diode sld diode

Optical fiber transmission system;

Fiber optic gyroscope;

Fiber Optic Sensor;

Optical coherence tomography;

Optically measured light source.

4. Optical-Electrical Characteristics of 850nm 10mW Superluminescent Diode sld diode

Parameter Symbol Min. Typ. Max. Unit Notes
Operating current ITH - 180 220 mA CW
Power in fiber P 10 - - mW CW
3dB bandwidth Δλ 30 35   nm CW
Center length λC 830 850 870 nm CW
Spectrum modulation - - 0.1 0.2 dB -
Extinction ER - 16 - dB CW
TEC current IC - - 2 A TC = -45~+70℃
TEC voltage VC - - 3.5 V TC = -45~+70℃
Thermistor resistance Rth 9.5 10 10.5 TC = 25℃
Thermistor B constant B - 3950 - K -

5. Product Details of 850nm 10mW Superluminescent Diode sld diode

850nm SLED diode spectrum.

Package drawing&PIN-OUT Definition(Unit:mm)

  • PIN DESIGNATIONS PIN DESIGNATIONS
    1 TEC(+) 14 TEC(-)
    2 Thermistor 13 Case Ground
    3 NC 12 NC
    4 NC 11 SLD Cathode
    5 Thermistor 10 SLD Anode
    6 NC 9 NC
    7 NC 8 NC

6. Deliver,Shipping And Serving of 850nm 10mW Superluminescent Diode sld diode

All products have been tested before shipping out;

All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)

We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);

If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;

If the items are defective, please notify us within 3 days of delivery;

Any items must be returned in their original condition to qualify for a refund or replacement;

The buyer is responsible for all the shipping cost incurred.

7. FAQ

Q: what is the package you need?

A: Box optronics can customize the package according to your needs.

Q: What is the requirement for the output power?

A: Box optronics can customize according to your requirements.
