850nm 7mW SLEDs SLDs For Ophthalmic And Medical OCT

The 850nm 7mW SLEDs SLDs for ophthalmic and medical OCT is a light source for ophthalmic and medical OCT application, fiber transmission systems, fiber optic gyros, fiber optic sensors,optical coherence tomography, optical measurements. The diode is packaged in 14-pin standard butterfly package with monitor photodiode and thermo-electric cooler (TEC). Module is pigtailed with single mode polarization maintaining fiber and connectorized by FC/APC connector.

The 850nm 7mW SLEDs SLDs for ophthalmic and medical OCT is a light source for ophthalmic and medical OCT application, fiber transmission systems, fiber optic gyros, fiber optic sensors,optical coherence tomography, optical measurements. The diode is packaged in 14-pin standard butterfly package with monitor photodiode and thermo-electric cooler (TEC). Module is pigtailed with single mode polarization maintaining fiber and connectorized by FC/APC connector.

High output power 7mW;

14PIN BTF Package;

3dB bandwidth of >35nm;

Operating Temperature -45~+70℃;

SM fiber or PM fiber pigtail.

Optical fiber transmission system;

Fiber optic gyroscope;

Fiber Optic Sensor;

Optical coherence tomography;

Optically measured light source.

•

• PIN	DESIGNATIONS	PIN	DESIGNATIONS
  1	TEC（+）	14	TEC（-）
  2	Thermistor	13	Case Ground
  3	PD Anode	12	NC
  4	PD Cathode	11	SLD Cathode
  5	Thermistor	10	SLD Anode
  6	NC	9	NC
  7	NC	8	NC

All products have been tested before shipping out;

All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)

We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);

If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;

If the items are defective, please notify us within 3 days of delivery;

Any items must be returned in their original condition to qualify for a refund or replacement;

The buyer is responsible for all the shipping cost incurred.

A: Box optronics can customize the package according to your needs.

A: Box optronics can customize according to your requirements.
