Box Optronics visible wavelength laser light source module adopts FP semiconductor laser, single-mode fiber output, adjustable power, professionally designed high-precision, highstability current drive control board to ensure laser safety and stability, low noise operation, low cost, high cost performance, small and compact size, easy to integrate, widely used in scientific research, communication, medical treatment, spectral analysis, bioengineering and other fields. The light source equipment can be customized to provide dual-channel or four-channel fixed wavelength laser output.
Box Optronics visible wavelength laser light source module adopts FP semiconductor laser, single-mode fiber output, adjustable power, professionally designed high-precision, highstability current drive control board to ensure laser safety and stability, low noise operation, low cost, high cost performance, small and compact size, easy to integrate, widely used in scientific research, communication, medical treatment, spectral analysis, bioengineering and other fields. The light source equipment can be customized to provide dual-channel or four-channel fixed wavelength laser output.
● The output laser and power of different wavelength light sources can be customized;
● The output power of single-mode fiber is adjustable;
● Single-channel, dual-channel, quad-channel or multi-channel are optional;
● High output stability, small size, fast startup;
● Module or benchtop packaging is optional.
● Optical device testing;
● Biomedical sensing;
● Scientific research, etc.
| Parameter | Unit | Value | Notes | ||||||
| Working wavelength | nm | 488 | 520 | 650 | 780 | 850 | ±20nm | ||
| Output power | mW | 20 | 30 | 50 | 30 | 30 | Customiziable | ||
| Working mode | - | CW | |||||||
| Power adjustable rang | - | 10~100% | |||||||
| Short-term stability (15 min) | dB | ≤ ±0.02 | Equivalent ≤±0.5% | ||||||
| Long-term stability (8 hours) | dB | ≤ ±0.05 | Equivalent ≤±1.2% | ||||||
| Connector | - | FC/APC | Customiziable | ||||||
| Fiber type | - | 460HP | 630HP | Hi780 | Customiziable | ||||
| Dimension | 195(W)×220(D)×120(H) | Benchtop | |||||||
| 150(W)×125(D)×20(H) | Module | ||||||||
| 70(W)×90(D)×18(H) | Module | ||||||||
| Supply power | V | AC 110~240V, <20W | Benchtop | ||||||
| DC 5V/4A, <15W | Module | ||||||||
| Power consumption | W | ≤ 60 | |||||||
| Operating temperature | ℃ | -5 ~ +55 | |||||||
| Storage temperature | ℃ | -40 ~ +85 | |||||||
All products have been tested before shipping out;
All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)
We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);
If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;
If the items are defective, please notify us within 3 days of delivery;
Any items must be returned in their original condition to qualify for a refund or replacement;
The buyer is responsible for all the shipping cost incurred.
Q: What's the range of visible light?
A: 400-700nm.
Q: I need other wavelengths you don't refer to.
A: Please check with us if it's customized.
