1550nm Fiber Laser With Driver Module adopts DFB semiconductor laser chip, single-mode fiber output, professional design of driving circuit and TEC control to ensure the safe and stable operation of laser.
1550nm single wavelength laser source adopts DFB semiconductor laser chip, single-mode fiber output, professional design of driving circuit and TEC control to ensure the safe and stable operation of laser.
High output power;
Power and spectral stability;
Benchtop or Module package.
Optical sensor;
Fiber laser;
Research on nonlinear optics.
| Parameters | Unit | Values | Notes |
| Operating wavelength | nm | 1550±0.5 | C-band ITU |
| Output power | mW | 10~2000 | Customizable |
| Spectral linewidth | MHz | ≤ 3 | 100KHz, 1MHz |
| Side mode suppression ratio | dB | > 50 | |
|
Power instability (Short-term 15mins) |
dB | ≤±0.02 | |
|
Power instability (Long-term 8hours) |
dB | ≤±0.05 | |
| Connector | - | FC/APC | |
| Fiber type | - | SMF-28e | |
| Dimensions | mm | 260(W)×280(D)×120(H) | Benchtop |
| 150(W)×125(D)×30(H) | Module | ||
| Power supply | V | AC 110~240V | Benchtop |
| DC 5V/4A | Module | ||
| Communication interface | - | DB9 Female(RS232) | |
| Operating temperature | ℃ | -20 ~ +65 | |
| Storage temperature | ℃ | -40 ~ +85 |
All products have been tested before shipping out;
All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)
We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);
If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;
If the items are defective, please notify us within 3 days of delivery;
Any items must be returned in their original condition to qualify for a refund or replacement;
The buyer is responsible for all the shipping cost incurred.
A: We have 1530nm 1550nm 1560nm options.
Q: What is the requirement for the output power?A: We have 10mW 100mW and 1000mW, we can also customize according to your requirement.
Q: About the package dimension, do you have any requirement?A: We have the module type and benchtop for choice.
