The 1060nm SLD broadband light source uses a superluminescent diode to output a broadband spectrum and has a high output power, which is suitable for applications such as fiber optic sensing. It can provide a communication interface and host computer software to facilitate the monitoring of the light source status.
The 1060nm SLD broadband light source uses a superluminescent diode to output a broadband spectrum and has a high output power, which is suitable for applications such as fiber optic sensing. It can provide a communication interface and host computer software to facilitate the monitoring of the light source status.
Ultra-wide spectrum;
Low spectral ripple;
Spectral flatness;
Customizable size.
Fiber sensor;
Medical imaging;
Fiber optic device testing.
| Parameters | Unit | Values | Notes |
| Operating wavelength | nm | 1060 | |
| Output power | mW | 5/10 | |
| -3dB bandwidth | nm | >20 | |
| Short-term stability (15 minutes) | dB | ≤±0.02 | |
| Long-term stability (8 hours) | dB | ≤±0.05 | |
| Dimensions | mm | 195(W)×220(D)×120(H) | Benchtop |
| 150(W)×125(D)×30(H) | Module | ||
| Power supply | V | AC 110~240V | Benchtop |
| DC 5V/4A | Module | ||
| Degree of polarization(DOP) | dB | ≤ 1 | |
| Connector | - | FC/APC | |
| Fiber type | - | Hi1060/PM980 fiber | |
| Communication Interface | - | DB9 Female(RS232) | |
| Operating temperature | ℃ | -20 ~ +55 | |
| Storage temperature | ℃ | -40 ~ +85 |
All products have been tested before shipping out;
All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)
We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);
If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;
If the items are defective, please notify us within 3 days of delivery;
Any items must be returned in their original condition to qualify for a refund or replacement;
The buyer is responsible for all the shipping cost incurred.
A: 840nm 1064nm 1310nm 1550nm wavelength.
Q: What is the requirement for the output power?A: We have 0.2mW 0.3mW 1mW 2mW 10mW 15mW options, we can also our customize according to your requirement.
Q: About the package dimension, do you have any requirement?A: We have the module type and benchtop for choice.
