C+L Band Wide Wavelength ASE Broadband Light Source Module

You can rest assured to buy C+L Band Wide Wavelength ASE Broadband Light Source Module from our factory and we will offer you the best after-sale service and timely delivery.

Send Inquiry

Product Description

1. Introduction of C+L Band Wide Wavelength ASE Broadband Light Source Module

The optical fiber ASE broadband light source module uses spectral flattening technology, and at the same time has a higher output power, and the operating wavelength covers the C + L band, which is suitable for applications such as optical fiber sensing. RS-232 interface and host computer software can be provided to facilitate the monitoring of the status of the light source module.

2. Feature of C+L Band Wide Wavelength ASE Broadband Light Source Module

Power stability;

Flat spectrum;

Remote monitoring.

3. Application of C+L Band Wide Wavelength ASE Broadband Light Source Module

Fiber optic sensing;

Medical imaging;

Fiber optic device testing.

4. Optical-Electrical Characteristic of C+L Band Wide Wavelength ASE Broadband Light Source Module

Parameters Unit Values Notes
Operating wavelength nm 1528~1603 C+L Band
Output power mW 10/20/50/100
Power adjustable(optional) - Adjustment range 10% ~ 100% Constant spectral flatness
Spectral flatness dB 2.5(Typ.), 3(Max.)
Power instability
(Short-term 15mins)
dB ≤±0.02
Power instability
(Long-term 8hours)
dB ≤±0.05
Degree of polarization dB ≤0.2
Connector - FC/APC
Fiber type - SMF-28e
Dimensions mm 260(W)×280(D)×120(H) Benchtop
150(W)×125(D)×20(H) Module
Power supply V AC 110~240V, <30W Benchtop
DC 5V, <15W Module
Communication interface - DB9  Female(RS232)
Operating temperature -5 ~ +55
Storage temperature -40 ~ +85

5. Typical Characteristic Curve of C+L Band Wide Wavelength ASE Broadband Light Source Module

C+L Band Wide Wavelength ASE Broadband Light Source Module

6. Deliver,Shipping And Serving of C+L Band Wide Wavelength ASE Broadband Light Source Module

All products have been tested before shipping out;

All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)

We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);

If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;

If the items are defective, please notify us within 3 days of delivery;

Any items must be returned in their original condition to qualify for a refund or replacement;

The buyer is responsible for all the shipping cost incurred.

C+L Band Wide Wavelength ASE Broadband Light Source Module

7. FAQ

Q: what is output power would you like?

A: We have 10mW 20mW 50mW 100mW, we can also customize according to your requirement.

Q: About the package dimension, do you have any requirement?

A: We have the module type and benchtop for choice.
