Boxoptronics' large mode area 6.5/125µm single clad ytterbium doped fiber has high slope efficiency and low photon darkening performance.This fiber is very suitable for high-power continuous and pulsed fiber lasers.
Boxoptronics' large mode area 6.5/125µm single clad ytterbium doped fiber has high slope efficiency and low photon darkening performance.This fiber is very suitable for high-power continuous and pulsed fiber lasers.
High stable performance.
High pulse energy fiber laser;
Fiber laser.
| Part No.: | BYSF-6.5/125-I | |
| Optical Specifications | Operating wavelength | 1030-1100nm |
| Core Numerical Aperture | 0.12 ± 0.01 | |
| Core absorption @976nm | 280.0 ± 50.0 dB/m | |
| Fiber core attenuation @1200nm | ≤ 15.0 dB/km | |
|
Dimensions and Mechanical Specifications |
Core diameter | 6.5 ± 0.5μm |
| Cladding diameter | 125.0 ± 10.0μm | |
| Coating diameter | 245.0 ± 10.0μm | |
| Cladding shape | Round | |
| Mechanical strength | ≥100kpsi | |
| Coating materials | High Refractive Index Resin | |
| Matrix material | Quartz | |
