1550nm Superluminescent Diodes SLED

1550nm Superluminescent Diodes SLED are optical sources with a rather wide optical bandwidth. In that they differ from both lasers, that have a very narrow spectrum, and white light sources, that exhibit a much larger spectral width. This characteristic mainly reflects itself in a low temporal coherence of the source (which is the limited capability of the emitted light wave to maintain the phase over time). SLED may however exhibit a high degree of spatial coherence, meaning that they can be efficiently coupled into single-mode optical fibers. Some applications take advantage of the low temporal coherence of SLED sources to achieve high spatial resolution in imaging techniques. The coherence length is a quantity frequently used to characterize the temporal coherence of the light source. It is related to the path difference between the two arms of an optical interferometer over which the light wave is still capable to generate an interference pattern.

Send Inquiry

Product Description

1. Summary of 1550nm Superluminescent Diodes SLED

1550nm Superluminescent Diodes SLED are optical sources with a rather wide optical bandwidth. In that they differ from both lasers, that have a very narrow spectrum, and white light sources, that exhibit a much larger spectral width. This characteristic mainly reflects itself in a low temporal coherence of the source (which is the limited capability of the emitted light wave to maintain the phase over time). SLED may however exhibit a high degree of spatial coherence, meaning that they can be efficiently coupled into single-mode optical fibers. Some applications take advantage of the low temporal coherence of SLED sources to achieve high spatial resolution in imaging techniques. The coherence length is a quantity frequently used to characterize the temporal coherence of the light source. It is related to the path difference between the two arms of an optical interferometer over which the light wave is still capable to generate an interference pattern.

2. Introduction of 1550nm Superluminescent Diodes SLED

1550nm Superluminescent Diodes SLED are optical sources with a rather wide optical bandwidth. In that they differ from both lasers, that have a very narrow spectrum, and white light sources, that exhibit a much larger spectral width. This characteristic mainly reflects itself in a low temporal coherence of the source (which is the limited capability of the emitted light wave to maintain the phase over time). SLED may however exhibit a high degree of spatial coherence, meaning that they can be efficiently coupled into single-mode optical fibers. Some applications take advantage of the low temporal coherence of SLED sources to achieve high spatial resolution in imaging techniques. The coherence length is a quantity frequently used to characterize the temporal coherence of the light source. It is related to the path difference between the two arms of an optical interferometer over which the light wave is still capable to generate an interference pattern.

3. Features of 1550nm Superluminescent Diodes SLED

Output power 1mW 2mW or 10mW;

Center wavelength 1550nm;

3dB bandwidth of >35nm;

Operating Temperature-45~+70℃;

SM fiber or PM fiber pigtail;

4. Application of 1550nm Superluminescent Diodes SLED

Fiber optic communications system;

Fiber optic Gyroscopes;

Fiber optic sensors;

Optical test instruments;

Optical coherence tomography(OCT);

Biomedical imaging systems.

5. Optical-Electrical Characteristics of 1550nm Superluminescent Diodes SLED

Parameter Symbol Min. Typ. Max. Unit Notes
Operating Current ITH - 100 200 mA CW
Power in Fiber PO 1.0 2.0 2.5 mW CW, ITH=100mA
3dB bandwidth Δλ 35 - - nm CW
Center wavelength λc 1530 1550 1570 nm CW
Spectrum modulation - - 0.1 0.2 dB -
Extinction ER - 16 - dB CW
TEC Current IC - - 2 A Tc =-45~+70℃
TEC Voltage VC - - 3.5 V Tc =-45~+70℃
Thermistor resistance Rth 9.5 10 10.5 Tc =25℃
Thermistor B constant B - 3950 - K -

6. Product Details of 1550nm Superluminescent Diodes SLED

Dimensions are in millimeters. All dimensions are ±0.2mm unless otherwise specified. (Unit: mm).
  • PIN DESIGNATIONS PIN DESIGNATIONS
    1 TEC(+) 14 TEC(-)
    2 Thermistor 13 Case Ground
    3 NC 12 NC
    4 NC 11 SLD Cathode
    5 Thermistor 10 SLD Anode
    6 NC 9 NC
    7 NC 8 NC

7. Deliver,Shipping And Serving of 1550nm Superluminescent Diodes SLED

All products have been tested before shipping out;

All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)

We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);

If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;

If the items are defective, please notify us within 3 days of delivery;

Any items must be returned in their original condition to qualify for a refund or replacement;

The buyer is responsible for all the shipping cost incurred.

8. FAQ

Q: what is the applications and wavelength accuracy?

A: Box optronics can provide 1mW to 15mW versions for choice.

Q: What is the optical connector you requirement?

A: Box optronics can customize the optical connector according the requirement for free.
