975nm 976nm 980nm 50W Multi-Mode Pump Laser Module

The 975nm 976nm 980nm 50W Multi-Mode Pump Laser Module is single Emitter Laser Diodes High coupling efficiency laser diode.

Send Inquiry

Product Description

1. Summary of 975nm 976nm 980nm 50W Multi-Mode Pump Laser Module

The 975nm 976nm 980nm 50W Multi-Mode Pump Laser Module is single Emitter Laser Diodes High coupling efficiency laser diode.

2. Introduction of 975nm 976nm 980nm 50W Multi-Mode Pump Laser Module

The 975nm 976nm 980nm 50W Multi-Mode Pump Laser Module is single Emitter Laser Diodes High coupling efficiency laser diode.

3. Features of 975nm 976nm 980nm 50W Multi-Mode Pump Laser Module

975nm wavelength;

50W output power;

105µm fiber core diameter;

0.22NA.

4. Application of 975nm 976nm 980nm 50W Multi-Mode Pump Laser Module

Laser pumping;

Medical use;

Material processing.

5. Electro-Optical Characteristics(T=25℃) of 975nm 976nm 980nm 50W Multi-Mode Pump Laser Module

Parameter Symbol Min. Typ. Max. Unit
Operating output power Pout - 50.0 - W
Range of available wavelength λ 965 975 985 nm
Spectral width @ FWHM Δλ - 4.0 7.0 nm
Threshold current Ith - 0.5 0.9 A
Operating current at Pout IOP - 11.5 12.5 A
Operating voltage at Pout VOP - 8.25 10.0 V
Power conversion efficiency - - 50 - %
Wavelength temperature coefficient Δλ/ΔT - 0.3 - nm/℃
Slope efficiency η - 5.0 - W/A
Fiber bend radius r 37.5 - - mm
Fiber core diameter DCOR - 105/125 - µm/µm
Fiber buffer diameter DBUF - 250 - µm
Fiber numerical aperture NA - 0.22 - -
Beam numerical aperture(95% power) Lf - 0.18 - NA
Fiber length Lf 0.9 1.5 - m
Connector type - Null or SMA905 -

6. Package drawing&PIN-OUT Definition(Unit:mm) of 975nm 976nm 980nm 50W Multi-Mode Pump Laser Module

7. Deliver,Shipping And Serving of 975nm 976nm 980nm 50W Multi-Mode Pump Laser Module

All products have been tested before shipping out;

All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)

We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);

If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;

If the items are defective, please notify us within 3 days of delivery;

Any items must be returned in their original condition to qualify for a refund or replacement;

The buyer is responsible for all the shipping cost incurred.

8. FAQ

Q: What is the wavelength you need?

A: We have 793nm 808nm 915nm 975nm laser diode.

Q: What is the requirement for the output power?

A: Box optronics can customize according to your requirements.
