793nm 20W High Brightness Fiber Pigtailed Diode Laser

The 793nm 20W High Brightness Fiber Pigtailed Diode Laser introduces a new high brightness single-emitter based, fiber-coupled diode laser pump module that delivers 20W output power into a 200um fiber core at a wavelength of 793nm, with a numerical aperture of 0.22NA.

Send Inquiry

Product Description

1. Summary of 793nm 20W High Brightness Fiber Pigtailed Diode Laser

The 793nm 20W High Brightness Fiber Pigtailed Diode Laser introduces a new high brightness single-emitter based, fiber-coupled diode laser pump module that delivers 20W output power into a 200um fiber core at a wavelength of 793nm, with a numerical aperture of 0.22NA.

2. Introduction of 793nm 20W High Brightness Fiber Pigtailed Diode Laser

The 793nm 20W High Brightness Fiber Pigtailed Diode Laser introduces a new high brightness single-emitter based, fiber-coupled diode laser pump module that delivers 20W output power into a 200um fiber core at a wavelength of 793nm, with a numerical aperture of 0.22NA.

3. Features of 793nm 20W High Brightness Fiber Pigtailed Diode Laser

793nm center wavelength;

20W Output power;

105/125μm 0.22NA Fiber;

High brightness;

RoHS Compliance.

4. Application of 793nm 20W High Brightness Fiber Pigtailed Diode Laser

Laser pumping;

Medical use;

Material processing.

5. Electro-Optical Characteristics(T=25℃) of 793nm 20W High Brightness Fiber Pigtailed Diode Laser

Parameter Symbol Min. Typ. Max. Unit
Operating output power Pout - 20.0 - W
Range of available wavelength λ 790 793 796 nm
Spectral width @ FWHM Δλ - 3.5 - nm
Threshold current Ith - 0.3 0.6 A
Operating current at Pout IOP - 3.5 4.0 A
Operating voltage at Pout VOP - 11.8 - V
Power conversion efficiency - - 45 - %
Wavelength temperature coefficient Δλ/ΔT - 0.3 - nm/℃
Slope efficiency η - 6.0 - W/A
Fiber bend radius r 37.5 - - mm
Fiber core/cladding diameter DCOR - 105/125 - µm/µm
Fiber buffer diameter DBUF - 250 - µm
Fiber numerical aperture NA - 0.22 - -
Beam numerical aperture(90% power) NA - 0.17 - -
Fiber length Lf - 1.2 - m
Connector type - Null or SMA905 -

6. Package drawing&PIN-OUT Definition(Unit:mm) of 793nm 20W High Brightness Fiber Pigtailed Diode Laser

7. Deliver,Shipping And Serving of 793nm 20W High Brightness Fiber Pigtailed Diode Laser

All products have been tested before shipping out;

All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)

We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);

If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;

If the items are defective, please notify us within 3 days of delivery;

Any items must be returned in their original condition to qualify for a refund or replacement;

The buyer is responsible for all the shipping cost incurred.

8. FAQ

Q: What is the wavelength you need?

A: We have 793nm 808nm 915nm 975nm laser diode.

Q: What is the requirement for the output power?

A: Box optronics can customize according to your requirements.
