The Pure Silica Core Multimode Energy Transmission Fiber is specially developed and designed for QBH transmission optical cable, and can transmit high-energy laser with low loss.
BoxOptronics Pure Silica Core Multimode Energy Transmission Fiber is specially developed and designed for QBH transmission optical cable, and can transmit high-energy laser with low loss.
Low Loss;
Excellent geometric consistency and core/cladding concentricity.
High power multimode output QBH.
| Part No: | BBD-50/70/360 | BBD-75/90/360 | BBD-100/120/360 | BBD-150/172/360 | BBD-150/180/360 |
| Operating wavelength | 800-2100nm | 800-2100nm | 800-2100nm | 800-2100nm | 800-2100nm |
| Fiber Core NA | 0.22±0.02 | 0.22±0.02 | 0.22±0.02 | 0.22±0.02 | 0.22±0.02 |
| Inner cladding NA | ≥0.46 | ≥0.46 | ≥0.46 | ≥0.46 | ≥0.46 |
| Fiber Core diameter | 50.0±2.0 um | 75.0±3.0 um | 100.0±2.0 um | 150.0±10.0 um | 150.0±3.0 um |
| First cladding diameter | 70.0±2.0 um | 90.0±5.0 um | 120.0±2.0 um | 172.5±2.0 um | 180.0±3.0 um |
| Second cladding diameter | 360.0±3.0 um | 360.0±7.0 um | 360.0±3.0 um | 360.0±3.0 um | 360.0±3.0 um |
| Coating diameter | 535.0±15.0 um | 535.0±15.0 um | 535.0±15.0 um | 535.0±15.0 um | 535.0±15.0 um |
| Coating materials | Low refractive index coating | Low refractive index coating | Low refractive index coating | Low refractive index coating | Low refractive index coating |
| Bending radius (short time) | ≥18mm | - | ≥18mm | - | - |
| Bending radius (Long time) | ≥54mm | ≥54mm | ≥54mm | ≥54mm | ≥54mm |
| Mechanical strength | ≥100kpsi | ≥100kpsi | ≥100kpsi | ≥100kpsi | ≥100kpsi |
All products have been tested before shipping out;
All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)
We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);
If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;
If the items are defective, please notify us within 3 days of delivery;
Any items must be returned in their original condition to qualify for a refund or replacement;
The buyer is responsible for all the shipping cost incurred.
A: C-band, L band, and C+L band wavelengths.
Q: What is the requirement for the output power?A: Box optronics can customize according to your requirements.
