High Power EDFA Amplifier Module Manufacturers

Although both spectrum and frequency spectrum are electromagnetic spectrum, due to the difference in frequency, the analysis methods and test instruments of spectrum and frequency spectrum are very different. Some problems are difficult to solve in the optical domain, but it is easier to solve them through frequency conversion to the electrical domain.

The fiber cut-off wavelength is to ensure that only one mode exists in the fiber. One of the main transmission characteristics of single-mode fiber is the cut-off wavelength, which is of great significance for fiber optic cable manufacturers and users of fiber optic cables to design and use fiber optic transmission systems.

The fiber optic sensor network has three basic components, one of which is called a single-point sensor. An optical fiber only plays the role of transmission here, and the other is called a multi-point sensor, where one optical fiber connects many sensors together so that many sensors can share the light source to realize network monitoring. Then there is the smart fiber optic sensor. The multi-point optical fiber sensor is a grating from the outside, and periodic intervals are found through ultraviolet irradiation. When an optical fiber is incident, if the wavelength of the optical fiber is exactly twice the interval, the light wave will be strongly reflected, and if the optical fiber is subjected to temperature changes or strains, the reflected wavelength will change. This kind of sensor There can be many on one fiber, and it can be used for a variety of sensing applications by connecting them.

ASE light source is specially designed for laboratory experiment and production. The main part of the light source is gain medium erbium-doped fiber and high-performance pump laser. The unique ATC and APC circuits ensure the stability of the output power by controlling the output of the pump laser. By adjusting APC, the output power can be adjusted within a certain range. Simple and intelligent operation and remote control.

When the incident light flux leaves from the illuminated surface or the incident surface of the medium to the other side, the ratio of the radiant energy projected and transmitted through the object to the total radiant energy projected on the object is called the transmittance of the object. The percentage of radiant energy reflected by an object to the total radiant energy is called reflectivity.

Fluorescence imaging has been widely used in biomedical imaging and clinical intraoperative navigation. When fluorescence propagates in biological media, absorption attenuation and scattering disturbance will cause fluorescence energy loss and signal-to-noise ratio decrease, respectively. Generally speaking, the degree of absorption loss determines whether we can "see", and the number of scattered photons determines whether we can "see clearly". In addition, the autofluorescence of some biomolecules and signal light are collected by the imaging system and eventually become the background of the image. Therefore, for biofluorescence imaging, scientists are trying to find a perfect imaging window with low photon absorption and sufficient light scattering.
